SN74LS00N

Quad 2-Input NAND Gate Array, 14-Pin Plastic Dual In-Line Package Profile, Low-Power Schottky (LS) Bipolar TTL Technology, 4.75V to 5.25V Standard Supply Voltage Window, Low Static Power Consumption Footprint, Balanced Propagation Delay Vector, High Input Noise Immunity Threshold, 10 Standard LSTTL Fanout Drive Capability, True Logic Function Output, 0°C to +70°C Standard Commercial Power Supply Window | Standard digital circuit building block manufactured by Texas Instruments utilizing high-performance low-power Schottky bipolar architecture to execute negative-AND logic across two separate hardware inputs per gate, optimized to deliver high-speed combinational logic operations cleanly, prevent intermediate switching voltage drops under varying temperature fluctuations, and safely coordinate combinational logic paths without propagation skew across automation control modules, consumer electronics control systems, and industrial timing arrays. | Industry Exact Equivalents:Texas Instruments SN74LS00N, TI 74LS00N, SN74LS00 | Industry Functional Cross-References:Motorola MC74LS00N, Nexperia 74LS00N, Toshiba TC74LS00P, Fairchild DM74LS00N | Military Specification National Stock Number (NSN): 5962-01-022-5400 [1]
