CD4514BE

CMOS 4-to-16 Line Decoder/Demultiplexer with Latch and Non-Inverting Outputs, standard 24-pin plastic dual-in-line package footprint manufactured by Texas Instruments. Provides sixteen independent active-high logical outputs from a latched 4-bit binary input word with low CMOS static power draw. Ideal for triggering subsequent high-current driver chips, hardware channel selectors, and point-of-load peripheral interfaces. Industry exact equivalents include Texas Instruments CD4514BE, Motorola MC14514BCP, Solid State Scientific SCL4514BE, and NTE4514B. Historical equipment applications include Atari Tron game inputs, Seeburg FC1 logic matrices, Oberheim Eight Voice synths, Bally Eight Ball Deluxe pinball, and Williams Defender units.
