R10-E1Z2-5800

800OHM low-signal, general-purpose electromechanical cradle relay - R10: Core product series (cradle style relay).E: Non-sealed polycarbonate dust cover.1: Solder/plug-in terminals.Z: Bifurcated crossbar contact style.2: DPDT (2 Form C) contact arrangement.S800: Sensitive DC coil version featuring an 800 Ω coil resistance and a low 180 mW power rating - Contact Rating: 2 Amps at 120 VAC (resistive) or 30 VDCContact Material: Fine Silver (Ag)Coil Voltage: 12 VDC nominalMounting Type: Plug-in / Socket mounting with standard mounting studsDimensions: 24.13 mm (Length) x 18.66 mm (Width) x 29.97 mm (Height)
